Parameter

Specification

Note

Wavelength Range (nm)

850

1064

1310

O Band

1530-1570

C band

1570-1610

L band

Attenuation Type

Brighter Dark

Attenuation Range(dB)

≥ 30

For Single Mode

≥ 25

For Multi Mode

Blocking state Attenuallon(dB)

≥ 40

Dark Type

Insertion Loss(dB)

≤ 0.7(TYPICAL0.5)

For Single Mode

≤ 1.2(TYPICAL0.5)

For Multi Mode

Attenuation Resolution (dB)

Continuous

Wavelength Dependent Loss(dB)

≤ 0.3

@<0 dB Att.

≤ 1.5

@<20 dB Att.

Polarization Dependent Loss(dB)

0.1

@<0 dBAtt.

0.5

@<20 dBAtt.

Temperture Dependent Loss(dB)

≤ 0.7

@<0 dB Att. compare with RT

≤ 1.0

@<20 dB Att. compare with RT

Returnloss (dB)

≥ 45

For Single Mode

≥ 30

For Multi Mode

PMD(ps)

< 0.1

Respnse Time(ms)

≥ 3

10-90% optical power

Optical Power Handing (mW)

300

Driving Voltage (V)

6.5 or 15

Power Consumption(mW)

≤ 2

Operation Temperature (°C)

0-70

Storage Temperature (°C)

-125
